pip install langchain langgraph google-cloud-aiplatform langchain-google-genai google-adk deprecated pydantic

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102

# Copyright (c) 2025 Marco Fago
# https://www.linkedin.com/in/marco-fago/
#
# This code is licensed under the MIT License.
# See the LICENSE file in the repository for the full license text.

from langchain_google_genai import ChatGoogleGenerativeAI
from langchain_core.prompts import ChatPromptTemplate
from langchain_core.output_parsers import StrOutputParser
from langchain_core.runnables import RunnablePassthrough, RunnableBranch

# --- Configuration ---
# Ensure your API key environment variable is set (e.g., GOOGLE_API_KEY)
try:
   llm = ChatGoogleGenerativeAI(model="gemini-2.5-flash", temperature=0)
   print(f"Language model initialized: {llm.model}")
except Exception as e:
   print(f"Error initializing language model: {e}")
   llm = None

# --- Define Simulated Sub-Agent Handlers (equivalent to ADK sub_agents) ---

def booking_handler(request: str) -> str:
   """Simulates the Booking Agent handling a request."""
   print("\n--- DELEGATING TO BOOKING HANDLER ---")
   return f"Booking Handler processed request: '{request}'. Result: Simulated booking action."

def info_handler(request: str) -> str:
   """Simulates the Info Agent handling a request."""
   print("\n--- DELEGATING TO INFO HANDLER ---")
   return f"Info Handler processed request: '{request}'. Result: Simulated information retrieval."

def unclear_handler(request: str) -> str:
   """Handles requests that couldn't be delegated."""
   print("\n--- HANDLING UNCLEAR REQUEST ---")
   return f"Coordinator could not delegate request: '{request}'. Please clarify."

# --- Define Coordinator Router Chain (equivalent to ADK coordinator's instruction) ---
# This chain decides which handler to delegate to.
coordinator_router_prompt = ChatPromptTemplate.from_messages([
   ("system", """Analyze the user's request and determine which specialist handler should process it.
    - If the request is related to booking flights or hotels,
      output 'booker'.
    - For all other general information questions, output 'info'.
    - If the request is unclear or doesn't fit either category,
      output 'unclear'.
    ONLY output one word: 'booker', 'info', or 'unclear'."""),
   ("user", "{request}")
])

if llm:
   coordinator_router_chain = coordinator_router_prompt | llm | StrOutputParser()

# --- Define the Delegation Logic (equivalent to ADK's Auto-Flow based on sub_agents) ---
# Use RunnableBranch to route based on the router chain's output.

# Define the branches for the RunnableBranch
branches = {
   "booker": RunnablePassthrough.assign(output=lambda x: booking_handler(x['request']['request'])),
   "info": RunnablePassthrough.assign(output=lambda x: info_handler(x['request']['request'])),
   "unclear": RunnablePassthrough.assign(output=lambda x: unclear_handler(x['request']['request'])),
}

# Create the RunnableBranch. It takes the output of the router chain
# and routes the original input ('request') to the corresponding handler.
delegation_branch = RunnableBranch(
   (lambda x: x['decision'].strip() == 'booker', branches["booker"]), # Added .strip()
   (lambda x: x['decision'].strip() == 'info', branches["info"]),     # Added .strip()
   branches["unclear"] # Default branch for 'unclear' or any other output
)

# Combine the router chain and the delegation branch into a single runnable
# The router chain's output ('decision') is passed along with the original input ('request')
# to the delegation_branch.
coordinator_agent = {
   "decision": coordinator_router_chain,
   "request": RunnablePassthrough()
} | delegation_branch | (lambda x: x['output']) # Extract the final output

# --- Example Usage ---
def main():
   if not llm:
       print("\nSkipping execution due to LLM initialization failure.")
       return

   print("--- Running with a booking request ---")
   request_a = "Book me a flight to London."
   result_a = coordinator_agent.invoke({"request": request_a})
   print(f"Final Result A: {result_a}")

   print("\n--- Running with an info request ---")
   request_b = "What is the capital of Italy?"
   result_b = coordinator_agent.invoke({"request": request_b})
   print(f"Final Result B: {result_b}")

   print("\n--- Running with an unclear request ---")
   request_c = "Tell me about quantum physics."
   result_c = coordinator_agent.invoke({"request": request_c})
   print(f"Final Result C: {result_c}")

if __name__ == "__main__":
   main()

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145

# Copyright (c) 2025 Marco Fago
#
# This code is licensed under the MIT License.
# See the LICENSE file in the repository for the full license text.

import uuid
from typing import Dict, Any, Optional

from google.adk.agents import Agent
from google.adk.runners import InMemoryRunner
from google.adk.tools import FunctionTool
from google.genai import types
from google.adk.events import Event

# --- Define Tool Functions ---
# These functions simulate the actions of the specialist agents.

def booking_handler(request: str) -> str:
   """
   Handles booking requests for flights and hotels.
   Args:
       request: The user's request for a booking.
   Returns:
       A confirmation message that the booking was handled.
   """
   print("-------------------------- Booking Handler Called ----------------------------")
   return f"Booking action for '{request}' has been simulated."

def info_handler(request: str) -> str:
   """
   Handles general information requests.
   Args:
       request: The user's question.
   Returns:
       A message indicating the information request was handled.
   """
   print("-------------------------- Info Handler Called ----------------------------")
   return f"Information request for '{request}'. Result: Simulated information retrieval."

def unclear_handler(request: str) -> str:
   """Handles requests that couldn't be delegated."""
   return f"Coordinator could not delegate request: '{request}'. Please clarify."

# --- Create Tools from Functions ---
booking_tool = FunctionTool(booking_handler)
info_tool = FunctionTool(info_handler)

# Define specialized sub-agents equipped with their respective tools
booking_agent = Agent(
   name="Booker",
   model="gemini-2.0-flash",
   description="A specialized agent that handles all flight
           and hotel booking requests by calling the booking tool.",
   tools=[booking_tool]
)

info_agent = Agent(
   name="Info",
   model="gemini-2.0-flash",
   description="A specialized agent that provides general information
      and answers user questions by calling the info tool.",
   tools=[info_tool]
)

# Define the parent agent with explicit delegation instructions
coordinator = Agent(
   name="Coordinator",
   model="gemini-2.0-flash",
   instruction=(
       "You are the main coordinator. Your only task is to analyze
        incoming user requests "
       "and delegate them to the appropriate specialist agent.
        Do not try to answer the user directly.\n"
       "- For any requests related to booking flights or hotels,
         delegate to the 'Booker' agent.\n"
       "- For all other general information questions, delegate to the 'Info' agent."
   ),
   description="A coordinator that routes user requests to the
     correct specialist agent.",
   # The presence of sub_agents enables LLM-driven delegation (Auto-Flow) by default.
   sub_agents=[booking_agent, info_agent]
)

# --- Execution Logic ---

async
 def run_coordinator(runner: InMemoryRunner, request: str):
   """Runs the coordinator agent with a given request and delegates."""
   print(f"\n--- Running Coordinator with request: '{request}' ---")
   final_result = ""
   try:
       user_id = "user_123"
       session_id = str(uuid.uuid4())
       await
 runner.session_service.create_session(
           app_name=runner.app_name, user_id=user_id, session_id=session_id
       )

       for event in runner.run(
           user_id=user_id,
           session_id=session_id,
           new_message=types.Content(
               role='user',
               parts=[types.Part(text=request)]
           ),
       ):
           if event.is_final_response() and event.content:
               # Try to get text directly from event.content
               # to avoid iterating parts
               if hasattr(event.content, 'text') and event.content.text:
                    final_result = event.content.text
               elif event.content.parts:
                   # Fallback: Iterate through parts and extract text (might trigger warning)
                   text_parts = [part.text for part in event.content.parts if part.text]
                   final_result = "".join(text_parts)
               # Assuming the loop should break after the final response
               break

       print(f"Coordinator Final Response: {final_result}")
       return final_result
   except Exception as e:
       print(f"An error occurred while processing your request: {e}")
       return f"An error occurred while processing your request: {e}"

async
 def main():
   """Main function to run the ADK example."""
   print("--- Google ADK Routing Example (ADK Auto-Flow Style) ---")
   print("Note: This requires Google ADK installed and authenticated.")

   runner = InMemoryRunner(coordinator)
   # Example Usage
   result_a = await run_coordinator(runner, "Book me a hotel in Paris.")
   print(f"Final Output A: {result_a}")
   result_b = await run_coordinator(runner, "What is the highest mountain in the world?")
   print(f"Final Output B: {result_b}")
   result_c = await run_coordinator(runner, "Tell me a random fact.") # Should go to Info
   print(f"Final Output C: {result_c}")
   result_d = await run_coordinator(runner, "Find flights to Tokyo next month.") # Should go to Booker
   print(f"Final Output D: {result_d}")

if __name__ == "__main__":
   import nest_asyncio
   nest_asyncio.apply()
   await main()
