# Example: Using InMemorySessionService
# This is suitable for local development and testing where data
# persistence across application restarts is not required.
from google.adk.sessions import InMemorySessionService
session_service = InMemorySessionService()


Then there's DatabaseSessionService if you want reliable saving to a database you manage.
# Example: Using DatabaseSessionService
# This is suitable for production or development requiring persistent storage.
# You need to configure a database URL (e.g., for SQLite, PostgreSQL, etc.).
# Requires: pip install google-adk[sqlalchemy] and a database driver (e.g., psycopg2 for PostgreSQL)
from google.adk.sessions import DatabaseSessionService
# Example using a local SQLite file:
db_url = "sqlite:///./my_agent_data.db"
session_service = DatabaseSessionService(db_url=db_url)




Besides, there's VertexAiSessionService which uses Vertex AI infrastructure for scalable production on Google Cloud.
# Example: Using VertexAiSessionService
# This is suitable for scalable production on Google Cloud Platform, leveraging
# Vertex AI infrastructure for session management.
# Requires: pip install google-adk[vertexai] and GCP setup/authentication
from google.adk.sessions import VertexAiSessionService

PROJECT_ID = "your-gcp-project-id" # Replace with your GCP project ID
LOCATION = "us-central1" # Replace with your desired GCP location
# The app_name used with this service should correspond to the Reasoning Engine ID or name
REASONING_ENGINE_APP_NAME = "projects/your-gcp-project-id/locations/us-central1/reasoningEngines/your-engine-id" # Replace with your Reasoning Engine resource name

session_service = VertexAiSessionService(project=PROJECT_ID, location=LOCATION)
# When using this service, pass REASONING_ENGINE_APP_NAME to service methods:
# session_service.create_session(app_name=REASONING_ENGINE_APP_NAME, ...)
# session_service.get_session(app_name=REASONING_ENGINE_APP_NAME, ...)
# session_service.append_event(session, event, app_name=REASONING_ENGINE_APP_NAME)
# session_service.delete_session(app_name=REASONING_ENGINE_APP_NAME, ...)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45

# Import necessary classes from the Google Agent Developer Kit (ADK)
from google.adk.agents import LlmAgent
from google.adk.sessions import InMemorySessionService, Session
from google.adk.runners import Runner
from google.genai.types import Content, Part

# Define an LlmAgent with an output_key.
greeting_agent = LlmAgent(
   name="Greeter",
   model="gemini-2.0-flash",
   instruction="Generate a short, friendly greeting.",
   output_key="last_greeting"
)

# --- Setup Runner and Session ---
app_name, user_id, session_id = "state_app", "user1", "session1"
session_service = InMemorySessionService()
runner = Runner(
   agent=greeting_agent,
   app_name=app_name,
   session_service=session_service
)
session = session_service.create_session(
   app_name=app_name,
   user_id=user_id,
   session_id=session_id
)

print(f"Initial state: {session.state}")

# --- Run the Agent ---
user_message = Content(parts=[Part(text="Hello")])
print("\n--- Running the agent ---")
for event in runner.run(
   user_id=user_id,
   session_id=session_id,
   new_message=user_message
):
   if event.is_final_response():
     print("Agent responded.")

# --- Check Updated State ---
# Correctly check the state *after* the runner has finished processing all events.
updated_session = session_service.get_session(app_name, user_id, session_id)
print(f"\nState after agent run: {updated_session.state}")

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68

import time
from google.adk.tools.tool_context import ToolContext
from google.adk.sessions import InMemorySessionService

# --- Define the Recommended Tool-Based Approach ---
def log_user_login(tool_context: ToolContext) -> dict:
   """
   Updates the session state upon a user login event.
   This tool encapsulates all state changes related to a user login.
   Args:
       tool_context: Automatically provided by ADK, gives access to session state.
   Returns:
       A dictionary confirming the action was successful.
   """
   # Access the state directly through the provided context.
   state = tool_context.state

   # Get current values or defaults, then update the state.
   # This is much cleaner and co-locates the logic.
   login_count = state.get("user:login_count", 0) + 1
   state["user:login_count"] = login_count
   state["task_status"] = "active"
   state["user:last_login_ts"] = time.time()
   state["temp:validation_needed"] = True

   print("State updated from within the `log_user_login` tool.")

   return {
       "status": "success",
       "message": f"User login tracked. Total logins: {login_count}."
   }

# --- Demonstration of Usage ---
# In a real application, an LLM Agent would decide to call this tool.
# Here, we simulate a direct call for demonstration purposes.

# 1. Setup
session_service = InMemorySessionService()
app_name, user_id, session_id = "state_app_tool", "user3", "session3"
session = session_service.create_session(
   app_name=app_name,
   user_id=user_id,
   session_id=session_id,
   state={"user:login_count": 0, "task_status": "idle"}
)
print(f"Initial state: {session.state}")

# 2. Simulate a tool call (in a real app, the ADK Runner does this)
# We create a ToolContext manually just for this standalone example.
from google.adk.tools.tool_context import InvocationContext
mock_context = ToolContext(
   invocation_context=InvocationContext(
       app_name=app_name, user_id=user_id, session_id=session_id,
       session=session, session_service=session_service
   )
)

# 3. Execute the tool
log_user_login(mock_context)

# 4. Check the updated state
updated_session = session_service.get_session(app_name, user_id, session_id)
print(f"State after tool execution: {updated_session.state}")

# Expected output will show the same state change as the
# "Before" case,
# but the code organization is significantly cleaner
# and more robust.

1
2
3
4
5
6

# Example: Using InMemoryMemoryService
# This is suitable for local development and testing where data
# persistence across application restarts is not required.
# Memory content is lost when the app stops.
from google.adk.memory import InMemoryMemoryService
memory_service = InMemoryMemoryService()

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

# Example: Using VertexAiRagMemoryService
# This is suitable for scalable production on GCP, leveraging
# Vertex AI RAG (Retrieval Augmented Generation) for persistent,
# searchable memory.
# Requires: pip install google-adk[vertexai], GCP
# setup/authentication, and a Vertex AI RAG Corpus.
from google.adk.memory import VertexAiRagMemoryService

# The resource name of your Vertex AI RAG Corpus
RAG_CORPUS_RESOURCE_NAME = "projects/your-gcp-project-id/locations/us-central1/ragCorpora/your-corpus-id" # Replace with your Corpus resource name

# Optional configuration for retrieval behavior
SIMILARITY_TOP_K = 5 # Number of top results to retrieve
VECTOR_DISTANCE_THRESHOLD = 0.7 # Threshold for vector similarity

memory_service = VertexAiRagMemoryService(
   rag_corpus=RAG_CORPUS_RESOURCE_NAME,
   similarity_top_k=SIMILARITY_TOP_K,
   vector_distance_threshold=VECTOR_DISTANCE_THRESHOLD
)
# When using this service, methods like add_session_to_memory
# and search_memory will interact with the specified Vertex AI
# RAG Corpus.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

from langchain.memory import ChatMessageHistory

# Initialize the history object
history = ChatMessageHistory()

# Add user and AI messages
history.add_user_message("I'm heading to New York next week.")
history.add_ai_message("Great! It's a fantastic city.")

# Access the list of messages
print(history.messages)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

from langchain.memory import ConversationBufferMemory

# Initialize memory
memory = ConversationBufferMemory()

# Save a conversation turn
memory.save_context({"input": "What's the weather like?"}, {"output": "It's sunny today."})

# Load the memory as a string
print(memory.load_memory_variables({}))

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

from langchain_openai import OpenAI
from langchain.chains import LLMChain
from langchain.prompts import PromptTemplate
from langchain.memory import ConversationBufferMemory

# 1. Define LLM and Prompt
llm = OpenAI(temperature=0)
template = """You are a helpful travel agent.

Previous conversation:
{history}

New question: {question}
Response:"""
prompt = PromptTemplate.from_template(template)

# 2. Configure Memory
# The memory_key "history" matches the variable in the prompt
memory = ConversationBufferMemory(memory_key="history")

# 3. Build the Chain
conversation = LLMChain(llm=llm, prompt=prompt, memory=memory)

# 4. Run the Conversation
response = conversation.predict(question="I want to book a flight.")
print(response)
response = conversation.predict(question="My name is Sam, by the way.")
print(response)
response = conversation.predict(question="What was my name again?")
print(response)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

from langchain_openai import ChatOpenAI
from langchain.chains import LLMChain
from langchain.memory import ConversationBufferMemory
from langchain_core.prompts import (
   ChatPromptTemplate,
   MessagesPlaceholder,
   SystemMessagePromptTemplate,
   HumanMessagePromptTemplate,
)

# 1. Define Chat Model and Prompt
llm = ChatOpenAI()
prompt = ChatPromptTemplate(
   messages=[
       SystemMessagePromptTemplate.from_template("You are a friendly assistant."),
       MessagesPlaceholder(variable_name="chat_history"),
       HumanMessagePromptTemplate.from_template("{question}")
   ]
)

# 2. Configure Memory
# return_messages=True is essential for chat models
memory = ConversationBufferMemory(memory_key="chat_history", return_messages=True)

# 3. Build the Chain
conversation = LLMChain(llm=llm, prompt=prompt, memory=memory)

# 4. Run the Conversation
response = conversation.predict(question="Hi, I'm Jane.")
print(response)
response = conversation.predict(question="Do you remember my name?")
print(response)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

# Node that updates the agent's instructions
def update_instructions(state: State, store: BaseStore):
   namespace = ("instructions",)
   # Get the current instructions from the store
   current_instructions = store.search(namespace)[0]

   # Create a prompt to ask the LLM to reflect on the conversation
   # and generate new, improved instructions
   prompt = prompt_template.format(
       instructions=current_instructions.value["instructions"],
       conversation=state["messages"]
   )

   # Get the new instructions from the LLM
   output = llm.invoke(prompt)
   new_instructions = output['new_instructions']

   # Save the updated instructions back to the store
   store.put(("agent_instructions",), "agent_a", {"instructions": new_instructions})

# Node that uses the instructions to generate a response
def call_model(state: State, store: BaseStore):
   namespace = ("agent_instructions", )
   # Retrieve the latest instructions from the store
   instructions = store.get(namespace, key="agent_a")[0]

   # Use the retrieved instructions to format the prompt
   prompt = prompt_template.format(instructions=instructions.value["instructions"])
   # ... application logic continues

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

from langgraph.store.memory import InMemoryStore

# A placeholder for a real embedding function
def embed(texts: list[str]) -> list[list[float]]:
   # In a real application, use a proper embedding model
   return [[1.0, 2.0] for _ in texts]

# Initialize an in-memory store. For production, use a database-backed store.
store = InMemoryStore(index={"embed": embed, "dims": 2})

# Define a namespace for a specific user and application context
user_id = "my-user"
application_context = "chitchat"
namespace = (user_id, application_context)

# 1. Put a memory into the store
store.put(
   namespace,
   "a-memory",  # The key for this memory
   {
       "rules": [
           "User likes short, direct language",
           "User only speaks English & python",
       ],
       "my-key": "my-value",
   },
)

# 2. Get the memory by its namespace and key
item = store.get(namespace, "a-memory")
print("Retrieved Item:", item)

# 3. Search for memories within the namespace, filtering by content
# and sorting by vector similarity to the query.
items = store.search(
   namespace,
   filter={"my-key": "my-value"},
   query="language preferences"
)
print("Search Results:", items)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

from google.adk.memory import VertexAiMemoryBankService

agent_engine_id = agent_engine.api_resource.name.split("/")[-1]

memory_service = VertexAiMemoryBankService(
   project="PROJECT_ID",
   location="LOCATION",
   agent_engine_id=agent_engine_id
)

session = await session_service.get_session(
   app_name=app_name,
   user_id="USER_ID",
   session_id=session.id
)
await memory_service.add_session_to_memory(session)
